Fixed Report Creation

This guide covers how to create a report using the Fixed Report Template in OCTO.

Features of Fixed Template

  • Pre-configured insight reports with predefined layouts
  • Automatically structured based on selected time period

Dashboard Sections in Fixed Reports

Fixed reports include the following predefined dashboard sections with specific metrics:

1. Cloud Usage Analysis

This section provides detailed insights into your cloud spending patterns and trends.

Key Metrics Include: - Total cloud usage costs - Period-over-period comparison showing percentage and absolute changes - Daily average cost fluctuations - Visual cost overview graphs - Cost breakdown by service - Savings coverage breakdown analysis - Cost breakdown by account

2. Optimization Implementation Analysis

This section tracks the execution and effectiveness of cost optimization recommendations.

Key Metrics Include: - Total number of optimization suggestions generated - Number of optimizations actually executed - Cost vs. Savings - Savings breakdown by account - Optimization recommendations recorded

3. Estimated Usage Optimization Opportunities

This section identifies unrealized cost-saving opportunities in your current cloud usage.

Key Metrics Include: - Total unrealized savings potential for the reporting period - Highest impact optimization opportunities by service - Specific recommendations with projected savings amounts

4. Estimated Unrealized Rate Optimization Opportunities

This section focuses on rate optimization through reserved instances and savings plans.

Key Metrics Include: - Monthly unrealized savings from rate optimization - Specific savings plan recommendations - Account-specific optimization opportunities - Analysis based on 3-year term length and full upfront payment options

Steps to Create a Fixed Report

Step 1: Access Report Creation

• Navigate to the Dashboard.
• Click the dropdown beside the report name.
- If there are existing reports, click the dropdown and then select "+ New Report" to begin creating a new report.
- If no reports exist, a "Default" report is displayed. Click the dropdown beside it, then choose "+ New Report" to start creating a new one.

Dashboard New Report

Step 2: Choose Fixed Template

Select Fixed Template when prompted for the report type.

Fixed Temp

Step 3: Configure Report Parameters

Time Period Selection: Choose your reporting frequency: - Monthly - Quarterly - Yearly

Select Period

Report Details: - Report Name: Provide a descriptive name for easy identification - Description: Add detailed information about the report's purpose - Avatar/Color Theme: Customize visual appearance according to your preferences. - Member Access: Check the "Publish to Members" option to make the report visible to all platform members. Leave unchecked for private reports accessible only to the creator.

Details

Step 4: Select Cost Groups

Choose which cost groups should be included in the report. The selected cost groups will populate data for each widget in the report. Configure recurrence settings also.

  • Select Period
  • Fiscal year settings (if needed)

Select Costgroup

Step 5: Preview and Finalize

Preview Report: Click "Preview Report" to review the layout and content before finalizing.

Preview

Final Actions: - Save Layout: Confirm and save the report configuration - Cancel: Discard changes and exit report creation - Report Settings: Access additional configuration options to modify parameters
